Guide: troubleshooting OBD code P0352
OBD code P0352 indicates: Ignition Coil B Primary/Secondary Circuit Malfunction.1
| description | |
|---|---|
| P | powertrain |
| 0 | generic (not manufacturer specific) |
| 3 | ignition system |
| 5 | unknown |
| 2 | cylinder 2 |
Note the position of cylinder 2 on the below graph.
Figure 1: Cylinder order
Potential causes
- Defective ignition coil
- Defective spark plug
- Damaged/corroded/worn coil wiring
- Loose wiring connection or short
- Defective idle air control valve
- Carbon buildup in the throttle body
A defective ignition coil is generally considered the most common cause of this error. However, ignition coils can fail due to bad spark plugs. Try swapping the suspect coil to a different cylinder to rule out spark plugs and faulty wiring.2
Footnotes:
1
More information about this code: https://www.identifix.com/blogs/code-p0352-the-diagnostic-and-repair-guide
2
To change spark plugs (and ignition coils) see: guide-how-to-replace-spark-plugs-on-a-toyota-2gr-fe.html
